Register Widths
Overview
In each of the various sets of registers, each register can be referred to by different synonyms which determine how wide the register operation will be.
General Purpose Registers
| Intended Width | Register Prefix | Instruction Postfix |
|---|---|---|
| 8 bytes | x |
NA |
| 4 bytes | w |
NA |
| 2 bytes | w |
h |
| 1 byte | w |
b |
ldr (and ldp)
ldr x0, [sp] // load 8 bytes from address specified by sp
ldr w0, [sp] // load 4 bytes from address specified by sp
ldrh w0, [sp] // load 2 bytes from address specified by sp
ldrb w0, [sp] // load 1 byte from address specified by sp
The address from which a load is taking must match the alignment of what is being loaded.
str (and stp)
str x0, [sp] // store 8 bytes to address specified by sp
str w0, [sp] // store 4 bytes to address specified by sp
strh w0, [sp] // store 2 bytes to address specified by sp
strb w0, [sp] // store 1 byte to address specified by sp
The address to which a store is made must match the alignment of what is being stored.
Example
Let's look at this program:
.global main // 1
.text // 2
.align 2 // 3
// 4
main: mov x0, xzr // 5
ldr x1, =ram // 6
strb w0, [x1] // 7
strh w0, [x1] // 8
str w0, [x1] // 9
str x0, [x1] // 10
ret // 11
// 12
.data // 13
ram: .quad 0xFFFFFFFFFFFFFFFF // 14
// 15
.end // 16
// 17
Line 14 puts an identifiable pattern into 8 bytes of RAM and gives them the symbol ram.
Line 6 gets the address of these bytes into x1.
The next four lines put zeros into that memory using progressively wider store instructions.
The following is a gdb session running the above program. Line numbers have been added to assist with the description of the session. Rather than describe all after a wall of text, descriptions will be provided inline.
(gdb) b main // 1
Breakpoint 1 at 0x740: file align.s, line 5. // 2
Immediately after entering gdb we set a breakpoint at main.
(gdb) run // 3
Starting program: /media/psf/Home/buffet/3510/pk_do/regs/a.out // 4
// 5
Breakpoint 1, main () at align.s:5 // 6
5 main: mov x0, xzr // 7
We launched the program and gdb stops its execution upon reaching the breakpoint.
(gdb) p/x $x0 // 8
$1 = 0x1 // 9
Before putting zero into x0, let's see what it currently holds... the value 1. Recall this is argc. The p command means print and is used to print the values in registers. The modifier /x says to print in hexadecimal.
(gdb) n // 10
6 ldr x1, =ram // 11
(gdb) p/x $x0 // 12
$2 = 0x0 // 13
After putting zero into x0, we confirm its contents.
(gdb) p/x $x1 // 14
$3 = 0xfffffffff028 // 15
Prior to loading the address of 8 bytes found with the label ram, we print out the value already sitting in x1. The address it contains will be the address of the C-string containing the name of the program being run.
(gdb) n // 16
7 strb w0, [x1] // 17
(gdb) p/x $x1 // 18
$4 = 0xaaaaaaab1010 // 19
After loading the address of ram into x1, we confirm its contents.
(gdb) p/x &ram // 20
$5 = 0xaaaaaaab1010 // 21
Just for kicks, we confirm that the previous instruction really did get the address correctly.
(gdb) x/x &ram // 22
0xaaaaaaab1010: 0xffffffff // 23
We shift from print to examine to reach into memory and see what is found at ram.
(gdb) x/gx &ram // 24
0xaaaaaaab1010: 0xffffffffffffffff // 25
Adding the g (for giant) we can see all 8 bytes.
(gdb) n // 26
8 strh w0, [x1] // 27
(gdb) x/gx &ram // 28
0xaaaaaaab1010: 0xffffffffffffff00 // 29
We just did a strb and looking at memory, we see one byte's worth of zeros.
Note: this brings up an interesting question... which byte is actually sitting at the address of ram? We will have to look into this more later.
(gdb) n // 30
9 str w0, [x1] // 31
(gdb) x/gx &ram // 32
0xaaaaaaab1010: 0xffffffffffff0000 // 33
After storing a short.
(gdb) n // 34
10 str x0, [x1] // 35
(gdb) x/gx &ram // 36
0xaaaaaaab1010: 0xffffffff00000000 // 37
After storing an int.
(gdb) n // 38
11 ret // 39
(gdb) x/gx &ram // 40
0xaaaaaaab1010: 0x0000000000000000 // 41
(gdb) quit // 42
And finally, after storing a long.
Let's circle back to the question asked above: Which byte is actually at the address ram? When we examined the long just after putting in one byte of zero, we saw this:
(gdb) x/gx &ram // 28
0xaaaaaaab1010: 0xffffffffffffff00 // 29
Notice the zeros come at the end. Keep in mind, these bytes are printed as a long.
But what if we look at these 8 bytes individually?
(gdb) x/gx &ram
0xaaaaaaabb010: 0xffffffffffffff00
(gdb) x/8bx &ram
0xaaaaaaabb010: 0x00 0xff 0xff 0xff 0xff 0xff 0xff 0xff
Look at that... the least significant byte of a long comes first.
This is the definition of little endian.
The following image is from here:
Little Endian in More Detail
Given this program (not intended for meaningful execution... just examinging memory):
.global main // 1
.text // 2
.align 2 // 3
// 4
main: mov x0, xzr // 5
ret // 6
// 7
.data // 8
ram: .quad 0xAABBCCDDEEFF0011 // 9
.end // 10
let's take a look at the memory at location ram in two ways. Once interpreted as a long:
(gdb) x/gx &ram
0x11010: 0xaabbccddeeff0011
and then intrepreted as 8 bytes appearing in the order of lowest address to highest:
(gdb) x/8bx &ram
0x11010: 0x11 0x00 0xff 0xee 0xdd 0xcc 0xbb 0xaa
Compare the order of the bytes. They are least significant to most significant. Specifically:
- within a
longthe least significantintcomes first - within an
int, the least significantshortcomes first - within a
shortthe least significant byte comes first
Endiannes isn't an issue unless you're exchanging data with a computer that has a different endedness and then only if the data being transferred is longer in native width than 1 byte. Text, expressed in single bytes, is immune from endedness issues - text is an array of bytes and is the same on all platforms.
What Happens to the Rest of a Register When Only a Portion is Affected?
Whenever a narrower portion of a register is written to, the remainder of the registe is zero'd out. That is: strb overwrites the least significant byte of an x register and zeros out the upper 7 bytes.
There are dedicated instructions for manipulating bits in the middle of registers.
Casting Between int Type
Casting between integer types is in some cases accomplished by anding with 255 and 65535 (for char and short). Otherwise, see the previous section (What Happens to the Rest of a Register...).
